Welcome to the new Toolkit peers – Paolo, Matt, Jared and Irving

Slightly belated in some cases but I’d like to formally welcome four new toolkit peers. Paolo Amadini, Matthew Noorenberghe, Jared Wein and Irving Reid have all shown themselves to be well capable of reviewing patches in any of the toolkit code. Paolo, Matt and Jared actually got added a few months ago but apparently I failed to make an announcement at the time. Irving was added just last week. Please congratulate them all and don’t go too hard on their review queues!

Also if you think there are others who should be peers of Toolkit (or current peers that are no longer relevant) then please let me know.

An update for hgchanges

Nearly a year ago I showed off the first version of my webapp for displaying recent changes in mercurial repositories. I’ve heard directly from a number of people that use it but it’s had a few problems that I’ve spent some of my spare time trying to solve. I’m now pleased to say that a new version is up and running. I’m not sure it’s accurate to call this a rewrite since it was entirely incremental but when I look back over of the code changes there really isn’t much that wasn’t touched in some way or other. So what’s new? For you, a person using the site absolutely nothing! So what on earth have I been doing rewriting the code?

Hopefully I’ve been making the thing a whole lot more stable. Eagle eyed users may have noticed that periodically the site would stop updating, sometimes for days at a time. The site is split into two pieces. One is a django website to display the changes. The other is the important bit that reads the change data out of mercurial and puts it into a database that the website can use. I do this caching because it would be too expensive to work it out on the fly. The problem is that the process of reading the data out of mercurial meant keeping a local version of every repository on the server (some 5GB for the four currently tracked) and reading the changes using mercurial’s python API was slow and used a lot of memory. The shared hosting environment that I run this out of kept killing the process when it used too many resources. Normally it could recover but occasionally it would need a manual kick. Worse there is some mercurial bug where sometimes pulling a repository will end up with an inconsistent database. It’s rare so many people don’t see it but when you’re pulling repositories every ten minutes it starts happing every couple of weeks, again requiring manual work to fix the problem.

I did dabble with getting this into shape so I could run it on a mozilla server. PAAS seemed like the obvious option but after a lot of work it turned out that the database size restrictions there made this impossible. Since then I’ve seem so many horror stories about PAAS falling over that I think I’m glad I never got there. I also tried getting a dedicated server from Mozilla to run this on but they were quite rightly wary when I mentioned that the process used a bunch of memory and wanted harder figures before committing, unfortunately I never found out a way to give those figures.

The final solution has been ripping out the mercurial API dependency. Now rather than needing local mercurial repositories the import process instead talks to them over the web. The default mercurial web APIs aren’t great but luckily all of the repositories I care about have pushlog installed which has a good JSON API for retrieving recently pushed changesets. So now the process is to pull the recent pushlog, get the patches for every changeset and parse them to work out which files have changed. By not having to load the mercurial structures there is far less memory used and since the process now has to delay as it downloads each patch file it keeps the CPU usage low.

I’ve also made the database itself a lot more efficient. Previously I recorded every changeset for every repository, but many repositories have the same changeset in them. So by noting that the database gets a little more complicated but uses much less space and since you only have to parse the changeset once the import process becomes faster. It took me a while to get the website performing as fast as before with these changes but I think it’s there now (barring some strange slowness in Django that I can’t identify). I’ve also turned on some quite aggressive caching both on the client and server side, if someone has visited the same page as you’re trying to access recently then it should load super fast.

So, the new version is up and running at the same location as the old. Chances are you’re using it already so if you’re noticing any unexpected slowness or something not looking right please let me know.

Developer Tools meet-up in Portland

Two weeks ago the developer tools teams and a few others met in the Portland office for a very successful week of discussions and hacking. The first day was about setting the stage for the week and working out what everyone was going to work on. Dave Camp kicked us off with a review of the last six months in developer tools and talked about what is going to be important for us to focus on in 2014. We then had a little more in-depth information from each of the teams. After lunch a set of lightning talks went over some projects and ideas that people had been working on recently.

After that everyone got started prototyping new ideas, hacking on features and fixing bugs. The amount of work that happens at these meet-ups is always mind-blowing and this week was no exception, even one of our contributors got in on the action. Here is a list of the things that the team demoed on Friday:

This only covers the work demoed on Friday, a whole lot more went on during the week as a big reason for doing these meet-ups is so that groups can split off to have important discussions. We had Darrin Henein on hand to help out with UX designs for some of the tools and Kyle Huey joined us for a couple of days to help work out the final kinks in the plan for debugging workers. Lot’s of work went on to iron out some of the kinks in the new add-on SDK widgets for Australis, there were discussions about memory and performance tools as well as some talk about how to simplify child processes for Firefox OS and electrolysis.

Of course there was also ample time in the evenings for the teams to socialise. One of the downsides of being a globally distributed team is that getting to know one another and building close working relationships can be difficult over electronic forms of communication so we find that it’s very important to all come together in one place to meet face to face. We’re all looking forward to doing it again in about six months time.

An editable box model view in the devtools

This week the whole devtools group has been sequestered in Mozilla’s Portland office having one of our regular meet-ups. As always it’s been a fantastically productive week with lots of demos to show for it. I’ll be writing a longer write-up later but I wanted to post about what I played with over the week.

My wife does the odd bit of web development on the side. For a long time she was a loyal Firebug user and a while ago I asked her what she thought of Firefox’s built in devtools. She quickly pointed out a couple of features that Firebug had that Firefox did not. As I was leaving for this week I mentioned I’d be with the devtools group and she asked whether her features had been fixed yet. It turns out that colour swatches had been but the box model still wasn’t editable. So I figured I could earn myself some brownie points by hacking on that this week.

The goal here is to be able to inspect an element on the page, pull up the box model and be able to quickly play with the margins, borders and padding to tweak the positioning until it looks right. Then armed with the right values you can go update your stylesheets. It saves a lot of trial and error with positioning.

It turned out to be relatively simple to implement a pretty full version. The feature allows you to click one of the box model values and type whatever value you like, in any CSS unit you prefer. If the size had been set in the stylesheet in some specific unit then that is what appears in the input box for you to change. Better yet as you type numbers the element updates in the page on the fly and you can use the arrow keys to increase/decrease the value until you’re happy. It’s a really natural way to play with the element’s position.

The changes made appear on the element so you can find them in the rule view pretty easily. This patch is based on an updated version of the box model view which is why it looks so different to existing Firefox, all my work does is make the numbers editable.

I actually completed this so quickly that I decided to take this one step further. One thing missing from the box model display is information about border colours. So I added some colour swatches for each border and made them editable with the regular devtools colour picker.

Both of these patches are pretty much complete but they’ll have to wait for the new box model highlighter to be complete before they can be reviewed and land.

Six years revisited

Two years ago I blogged about how it had been six years since I wrote my first patch for Firefox. Today I get to say that it’s been six years since I started getting paid to do what I love, working for Mozilla. In that time I’ve moved to a new continent, found a wife (through Mozilla no less!), progressed from coder to module owner to manager, seen good friends leave for other opportunities and others join and watched (dare I say helped?) Mozilla, and the Firefox team in particular, grow from the small group that I joined in 2007 to the large company that will soon surpass 1000 employees.

One of the things I’ve always appreciated about Mozilla is how flexible they can be about where you work. Recently my wife and I decided to move away from the bay area to be closer to family. It was a hard choice to make as it meant leaving a lot of friends behind but one thing that made it easier was knowing that I wouldn’t have to factor work into that choice. Unlike many other companies I know there is no strict requirement that everyone work from the office. True it is encouraged and it sometimes makes sense to require it for some employees, particularly when starting out, but I knew that when it came time to talk to my manager about it he wouldn’t have a problem with me switching to working remote. Of course six years ago when I started I was living in the UK and remained so for my first two years at Mozilla so he had a pretty good idea that I could handle it, and at least this time I’m only separated from the main office by a short distance and no time-zones.

The web has changed a lot in the last six years. Back then we were working on Firefox 3, the first release to contain the awesomebar and a built-in way to download extensions from AMO. Twitter and Facebook had only been generally available for about a year. The ideas for CSS3 and HTML5 were barely written, let alone implemented. If you had told me back then that you’d be able to play a 3D game in your browser with no additional plugins, or watch videos without flash I’d have probably thought they were crazy pipe-dreams. We weren’t even Jitting our JS code back then. Mozilla, along with other browser makers, are continuing to prove that HTML, CSS and JS are winning combinations that we can build on to make the future of the web open, performant and powerful. I can’t wait to see what things will be like in another six years.

Firefox now ships with the add-on SDK

It’s been a long ride but we can finally say it. This week Firefox 21 shipped and it includes the add-on SDK modules.

We took all the Jetpack APIs and we shipped them in Firefox!What does this mean? Well for users it means two important things:

  1. Smaller add-ons. Since they no longer need to ship the APIs themselves add-ons only have to include the unique code that makes them special. That’s something like a 65% file-size saving for the most popular SDK based add-ons, probably more for simpler add-ons.
  2. Add-ons will stay compatible with Firefox for longer. We can evolve the modules in Firefox that add-ons use so that most of the time when changes happen to Firefox the modules seamlessly shift to keep working. There are still some cases where that might be impossible (when a core feature is dropped from Firefox for example) but hopefully those should be rare.

To take advantage of these benefits add-ons have to be repacked with a recent version of the SDK. We’re working on a plan to do that automatically for existing add-ons where possible but developers who want to get the benefits right now can just repack their add-ons themselves using SDK 1.14 and using cfx xpi --strip-sdk, or using the next release of the SDK, 1.15 which will do that by default.

Get notifications about changes to any directory in mercurial

Back in the old days when we used CVS of all things for our version control we had a wonderful tool called bonsai to help query the repository for changes. You could list changes on a per directory basis if you needed which was great for keeping an eye on certain chunks of code. I recall there being a way of getting an RSS feed from it and I used it when I was the module owner of the extension manager to see what changes were landed that I hadn’t noticed in bugs.

Fast forward to today and we use mercurial instead. When we switched there was much talk of how we’d get tool parity with CVS but bonsai is something that has never been replaced fully. Oh hgweb is decent at looking at individual files and browsing the tree, but you can’t get that list of changes per directory from it. I believe you can use the command line to do it but who wants to do that? Lately I’ve been finding need of those directory RSS feeds more and more. We’re now periodically uplifting the Add-on SDK repository to mozilla-central, it’s really important to spot changes that have been made to that directory in mozilla-central so we can also land them in our git repository and not clobber them the next time we uplift. I’m also the module owner of toolkit, which is a pretty big sprawling set of files. It seems like everytime I look I find something that landed without me noticing. I don’t make for a good module owner if I’m not keeping an eye on things so I’d really like to see when new files are added there.

So I introduce the Hg Change Feed, the result of mostly just a few days of work. Every 10 minutes it pulls new changes from mozilla-central and mozilla-inbound. A mercurial hook looks over the changes and adds information about them to a MySQL database. Then a simple django app displays that information. As you browse through the directories in the tree it shows only changesets that affected files beneath that directory. For any directory you can also get an RSS feed of the same. Plug that into IFTTT and you have an automated system to notify you in pretty much any way you’d like about new changes you’d be interested in.

Some simple examples. For tracking changes to Add-on SDK I’m watching http://hgchanges.fractalbrew.com/mozilla-inbound/file/addon-sdk/source. For toolkit I’m looking at http://hgchanges.fractalbrew.com/mozilla-inbound/file/toolkit?types=added. Types takes a comma separated list of “added”, “removed” and “modified” to filter which changes you’re interested in. There’s no UI on the site for changing that right now, you’re welcome to add some!

One other neat trick that this does is mostly ignore merge changesets. Only if a merge actually makes a change not already present in either of the merge parents (mostly happens when resolving merge conflicts) will it show up in the list of changes, because really you don’t need to hear about changes twice.

So play with it, let me know if you find it useful or if you think things are missing. I can also add other mercurial repositories if people want. Some caveats:

  • It only retains the last 2000 changesets from any repository in an effort to keep the DB size small and fast, it also only shows the last 200 changesets for each page, or just the last 20 in the feeds. These can be tweaked easily enough and I’ve done basically no benchmarking to say those are the right values.
  • The site isn’t as fast as I’d like, particularly listing changes for the top level directory takes nearly 5 seconds. I’ve thrown some basic caching in place to help alleviate that for now. I bet someone who has more MySQL and django experience than me could tell me what I’m doing wrong.
  • I’m off on vacation tomorrow so I guess I’m announcing this then running away, sorry if that means it takes me a while to respond to comments.

Want to help out and make it better? Go nuts with the source. There’s a readme that hopefully explains how to set up your own instance.

Hacking on Tilt

Tilt, or 3D view as it is known in Firefox, is an awesome visual tool that really lets you see the structure of a webpage. It shows you just how deep your tag hierarchy goes which might give signs of your page being too complex or even help you spot errors in your markup that you wouldn’t otherwise notice. But what if it could do more? What if there were different ways to visualise the same page? What if even web developers could create their own visualisations?

I’ve had this idea knocking around in my head for a while now and the devtools work week was the perfect time to hack on it. Here are some results, click through for larger images:

Normal 3D view

Normal 3D view

Only give depth to links

Only give depth to links

Only give depth to links going off-site

Only give depth to links going off-site

Only give depth to elements that have a different style on hover

Only give depth to elements that have a different style on hover

This is all achieved with some changes to Firefox itself to make Tilt handle more generic visualisations along with an extension that then overrides Tilt’s default visualisation. Because the extension has access to everything Firefox knows about the webpage it can use some interested sources of data about the page, including those not found in the DOM. This one I particularly like, it makes the element’s depth proportional to the number of attached DOM event listeners:

Give depth to elements based on the number of attached event listeners

Give depth to elements based on the number of attached event listeners

Just look at that search box, and what’s up with the two buttons having different height?

The code just calls a JS function to get the height for each element displayed in 3D view. It’s really easy to use DOM functions to highlight different things about the elements and while I think some of the examples I made are interesting I think it will be more interesting to just let web-devs come up with and share their own visualisations. To that end I also demoed using scratchpad to write whatever function you like to control the visualisation. You can see a screencast of it in action.

Something that struck me towards the end of the week is that it could be awesome to pair this up with external sources of data like analytics. What about being able to view your page with links given depth proportional to how often users click them? Seems like an awesome way to really understand where your users are going and maybe why.

I’m hoping to get the changes to Firefox landed soon maybe with an additional patch to properly support extensibility of Tilt, right now the extension works by replacing a function in a JSM which is pretty hacky, but it wouldn’t be difficult to make it nicer than that. After that I’ll be interested to see what visualisation ideas others come up with.

The Add-on SDK is now in Firefox

We’re now a big step closer to shipping the SDK APIs with Firefox and other apps, we’ve uplifted the SDK code from our git repository to mozilla-inbound and assuming it sticks we will be on the trains for releasing. We’ll be doing weekly uplifts to keep the code in mozilla-central current.

What’s changed?

Not a lot yet. Existing add-ons and add-ons built with the current version of the SDK still use their own versions of the APIs from their XPIs. Add-ons built with the next version of the SDK may start to try to use the APIs in Firefox in preference to those shipped with the XPI and then a future version will only use those in Firefox. We’re also talking about the possibility of making Firefox override the APIs in any SDK based add-on and use the shipped ones automatically so the add-on author wouldn’t need to do anything.

We’re working on getting the Jetpack tests running on tinderbox switched over to use the in-tree code, once we do we will be unhiding them so other developers can immediately see when their changes break the SDK code. You can now run the Jetpack tests with a mach command or just with make jetpack-tests from the object directory. Those commands are a bit rudimentary right now, they don’t give you a way to choose individual tests to run. We’ll get to that.

Can I use it now?

If you’re brave, sure. Once a build including the SDKs is out (might be a day or so for nightlies) fire up a chrome context scratch pad and put this code in it:

var { Loader } = Components.utils.import("resource://gre/modules/commonjs/toolkit/loader.js", {});
var loader = Loader.Loader({
  paths: {
    "sdk/": "resource://gre/modules/commonjs/sdk/",
    "": "globals:///"
  },
  resolve: function(id, base) {
    if (id == "chrome" || id.startsWith("@"))
      return id;
    return Loader.resolve(id, base);
  }
});
var module = Loader.Module("main", "scratchpad://");
var require = Loader.Require(loader, module);

var { notify } = require("sdk/notifications");
notify({
  text: "Hello from the SDK!"
});

Everything but the last 4 lines sets up the SDK loader so it knows where to get the APIs from and creates you a require function to call. The rest can just be code as you’d include in an SDK add-on. You probably shouldn’t use this for anything serious yet, in fact I haven’t included the code to tell the module loader to unload so this code example may leak things for the rest of the life of the application.

This is too long of course (longer than it should be right now because of a bug too) so one thing we’ll probably do is create a simple JSM that can give you a require function in one line as well as take care of unloading when the app goes away.

Pop-free sound from a Raspberry Pi running XBMC

UPDATE: I’ll leave this around for posterity but a large part of this problem has now been fixed in the latest Raspberry Pi firmware. See here for instructions for raspbmc until that gets updated.

I’ve been in the process of setting up a Raspberry Pi in my office so I can play my mp3 collection through my old stereo. It’s generally gone well and I have to take my hat off to the developers of Raspbmc which makes setting up XBMC on the Pi ridiculously easy and fast. It didn’t take me long to have Airplay set up and running as well as being able to use my phone to remote control XBMC to play things direct from my music library sitting on my Synology NAS. Quite a nice setup really.

Just one problem. I play the music out through the Pi’s audio jack which doesn’t have a fantastic DAC. The big noticeable issue is audible pops every-time XBMC starts and stops playing. For Airplay this isn’t too bad, you get a pop when it first starts but only another after you stop playing. Playing direct on XBMC though you get two pops between each track as it stops playing one and starts the next. Very annoying. It’s a pretty well known problem and the best solution so far is to simply never stop playing. If you have a player that uses pulseaudio then you can configure it to keep the audio stream going even when idle. Of course it isn’t that easy, XBMC doesn’t use pulseaudio on the Pi. There is some work going on that might change that but for now it is very buggy to the point of being unusable. It seemed I was stuck … or was I?

It took some experimentation but I finally came across something of a hack that solves the problem for me. It probably works on other distributions but I did all this using Raspbmc.

First as root you want to do this:

echo "snd-bcm2835" >>/etc/modules

This makes the kernel module for the sound devices load on startup. It allows alsa and by proxy pulseaudio to talk to the audio hardware. Next edit /etc/pulse/system.pa and comment out this line:

load-module module-suspend-on-idle

This tells pulseaudio to keep the audio stream alive even when not playing anything. Now reboot your Pi. Once it is started up copy a plain wav file (nothing mp3 encoded or anything) to the Pi, log in and play it through pulseaudio:

paplay test.wav

If it doesn’t come out of the speakers then alsa might be trying to play to the HDMI port. Try running this then running the above command again:

sudo amixer cset numid=3 1

What just happened is pulseaudio played the sound file, but now should have kept the audio hardware active and will continue to do so until the Pi is next turned off. You might think that that might mean that XBMC can’t play anything now. You’d be wrong, it plays just fine and no longer suffers from the popping between tracks. Occasionally I hear a pop when I first start playing after startup, but after that I’ve not heard any issues.

There are probably easier ways to initialise pulseaudio but I don’t mind playing some sound on every startup to let me know my Pi is ready. I made it automatic by sticking this at the top of .bashrc for the pi user (which is used to run xbmc):

/usr/bin/paplay $HOME/test.wav

It means it also plays every-time I log in with ssh but I’m not expecting to do that much now it’s all working. I’m sure someone will point out the better way to do this that I’m too lazy to look for now everything is working for me.
